Perforated Cable Trays

Perforated Cable Trays
Perforated Cable Trays
Product Code : 029
Product Description

Leveraging on our immense industry experience, we are competent to manufacture, supply and export a qualitative range of Perforated Cable Trays. These hot dip galvanized steel cable trays are offered in varied designs, dimensions and specifications. Offered trays are stringently checked on various quality parameters with our in-house testing under key supervision of our expert professionals.  Our cable trays are comprehensively used in telecommunication and electrical systems. Perforated Cable Trays, we offer are high in demand among the clients for the below enlisted attributes:

  • High electrical conductivity
  • Low thermal insulation
  • High endurance against environmental temperature
  • Impact resistance
  • Long lasting nature

Other details:

Cable Tray


Perforated Type Cable Tray offer an effective way to manage wiring while keeping it accessible, organized and secure. These systems accommodates large number of branch lines and offer high load-bearing capacity. Technician can install one or more dividers to separate power and data lines and organize cabling. For added cabling protection, perforated cable tray can be specified with or without covers. Ventilated louvers can also be specified to facilitate cooling by natural convection while keeping conductors enclosed and protected. Perforated cable tray may be hung using either a center rod support, C-hanger, or two hanger trapeze configuration and they can also be wall mounted using brackets.

Available in different sizes and specification (Painted Pre Galvanized, Hot Dip Galvanized, Powder Coated). As per requirement.

Available in M.S. Sheet, Pre Galvanized Sheet, Hot Dip Galvanized and Dip Painted.

Ladder Type Cable Tray is a cable tray consisting of two longitudinal side members connected by individual transverse members, designed for use as power cable or control cable support. Best constructed tray available for multiple large cables. Typically used by paper mills, power plants and industrial construction requiring strength and reliability. Exclusive Weld completely welds rungs to the outside of the rails for optimum structural integrity and reduced side rail rotation. Rung Spacings: 9", 12" and 18"; Load Depths: 3" through 5".Materials available: Aluminum, Steel, Steel HDGAF, Stainless Steel, PVC-coated Aluminum or Steel.

Cable tray is requred to provide path to cable to reach from power place to next use point. Cable Tray is also provide support to cables. The cables are tagged with the help of cable tie/ clamps on cable tray. Cable ray material steel standard IS 1079, 513, 8081 and for Hot Galvanizing IS 2629, 4759, 6745 400 gm/Kg.

General material of Cable Tray & its recommended use

  • G.I. Cable Tray : Inside & Outside

  • Powder Coated Cable Trat : Inside & Outside

  • Hot Galvanized Cable Tray : Outside

  • FRP Cable Tray : Chemical

  • Aluminum / SS Cable Tray : Clean Room / purification

    S.NO

    TYPE

    WIDTH

    DEPTH

    THICKNESS

    LENGTH

    FINISH

    MATERIAL

    1

    Perforated Type

    50-1000

    20-150

    1.2-3.0

    2500

    Point/G.I./Hot Galvanised

    FRP/SS/MS/GI

    2

    Ladder Type

    50-1000

    40-150

    1.2-3.0

    2500

    Point/G.I./Hot Galvanised

    SS/MS/GI

    3

    Raceway Type

    50-300

    20-150

    1.2-3.0

    2500

    Point/G.I./Hot Galvanised

    FRP/SS/MS/GI
